4700-05: Three Light Wall / Bath

	Collection: De-Lovely
	Four Light Bath Bracket with Chrome Finish.
	Four-light wall/bath fixture with chrome finish.
	UPC #:785652174780
	Finish: Chrome (05)

Dimensions:


Width:	18''
Height:	4 21/32''

Weight:

1.6 lbs.

Extends:

2 9/32''

Wire:

6 1/2'' (color/Black/White)

Mounting Proc.:

Wall / Bath

Connection:

Mounted To Box

Bulb Appearance:

Clear

Bulbs:

3 - Medium G25 100w Max. 120v - Not included

Features:

Clear bulb(s) recommended for this fixture

Material List:

1 Body - Steel - Chrome

Safety Listing:

Safety Listed for Damp Locations
Safety Listed for Damp Locations

Instruction Sheets:

English (HC-107)
French (F-006)
Trilingual (English, Spanish, and French) (4700 4701)

Backplate / Canopy Details:

Type	Height / Length	Width	Depth	Diameter	Outlet Box Up	Outlet Box Down
Canopy	4 21/32	18 3/32	1 1/32		2 5/16	2 5/16

Shipping Information:

Package Type	Product #	Quantity	UPC	Length	Width	Height	Cube	Weight	Frt. Class	UPS Ship
Individual	4700-05	1	785652174780	21.13	5.13	3	0.188	1.9	0	Yes
Master Pack	4700-05	6	10785652174787	22.5	11	9	1.289	12.4	0	Yes
