6514301EN7-112: One Light Pendant


Collection:  Bronzeville

UPC #:785652143267

Finish:   Midnight Black (112)
Dimensions:

Diameter: 14 1/4''
Width: 14 1/4''
Height: 17 5/8''
Overall Height: 62 1/8''
Wire: 72'' (color/Black)
Mounting Proc.: Center Lock-Up
Connection: Mounted To Box
Watts: 8
Lumens: 800
Bulb Temp: 2700 °K
Bulbs:
  1 - LED E26 Medium A19 8w Max. 120v - included
Features:
  • This product may be mounted on a sloped ceiling
  • LED Bulbs are an efficient, versatile and durable light source that deliver exceptional performance.
  • Meets Title 24 energy efficiency standards
  • Title 24 compliant when used with included Joint Appendix (JA8) approved lamp.
Material List:
1 Body - Steel - Midnight Black
3 12" Stem - Steel - Midnight Black
1 6" Stem - Steel - Midnight Black
Safety Listing:
  Safety Listed for Damp Locations

Shade / Glass / Diffuser Details:
Part Material Finish Quantity Item Number Length Width Height Diameter Fitter
Diameter		 Shade Top
Length		 Shade Top
Width		 Shade Top
Diameter
Shade Glass Clear Seeded 1       4 1/8 3 7/8
Backplate / Canopy Details:
Type Height / Length Width Depth Diameter Outlet Box Up Outlet Box Down
Canopy 3/4      5
Replacement Bulb Data:
Product #     Type Base Watts Watts Consumed Volts Hours Lumens Temp (°K) CRI
Shipping Information:
Package Type Product # Quantity UPC Length Width Height Cube Weight Frt. Class UPS Ship
Individual 6514301EN7-112 1  785652143267  10 21 16 1.944 9.3 0 Yes
Master Pack 6514301EN7-112 0  10785652143264
