6514303-112: Three Light Pendant


Collection:  Bronzeville

UPC #:785652141614

Finish:   Midnight Black (112)
Dimensions:

Diameter: 21 3/4''
Width: 21 3/4''
Height: 22 1/2''
Weight: 19.2 lbs.
Overall Height: 67''
Wire: 72'' (color/Black)
Mounting Proc.: Center Lock-Up
Connection: Mounted To Box
Bulbs:
  3 - E26 Medium ST19 60w Max. 120v - Not included
0 - E26 Medium A19 60w Max. 120v - Not included
Features:
  • This product may be mounted on a sloped ceiling
  • Easily converts to LED with optional replacement lamps
  • Meets Title 24 energy efficiency standards
  • Title 24 compliant if used with Joint Appendix (JA8) approved light bulbs listed in the California Energy Commission Appliance database.
Material List:
1 Body - Steel - Midnight Black
3 12" Stem - Steel - Midnight Black
1 6" Stem - Steel - Midnight Black
Safety Listing:
  Safety Listed for Damp Locations

Shade / Glass / Diffuser Details:
Part Material Finish Quantity Item Number Length Width Height Diameter Fitter
Diameter		 Shade Top
Length		 Shade Top
Width		 Shade Top
Diameter
Shade Glass Clear Seeded 30 G560324-112     4 1/8 3 7/8
Backplate / Canopy Details:
Type Height / Length Width Depth Diameter Outlet Box Up Outlet Box Down
Canopy 3/4      5
Shipping Information:
Package Type Product # Quantity UPC Length Width Height Cube Weight Frt. Class UPS Ship
Individual 6514303-112 1  785652141614  24.5 30 19.5 8.294 26.2 0 Yes
Master Pack 6514303-112 0  10785652141611
