7700503EN7-848: Three Light Semi-Flush Mount


Collection:  Axis

UPC #:785652127755

Finish:   Satin Brass (848)
Dimensions:

Diameter: 13''
Width: 13''
Height: 6''
Wire: 6 1/2'' (color/Black/White)
Mounting Proc.: Cap Nuts
Connection: Mounted To Box
Watts: 5
Lumens: 430
Bulb Temp: 2700 °K
Bulbs:
  3 - LED Medium A19 8w Max. 120v - included
Features:
  • LED Bulbs are an efficient, versatile and durable light source that deliver exceptional performance.
  • Meets Title 24 energy efficiency standards
  • Title 24 compliant when used with included Joint Appendix (JA8) approved lamp.
Material List:
1 Body - Steel - Satin Brass
Safety Listing:
  Safety Listed for Damp Locations
Instruction Sheets:
Trilingual (English, Spanish, and French) (7700503)

Backplate / Canopy Details:
Type Height / Length Width Depth Diameter Outlet Box Up Outlet Box Down
Canopy 3/4      5
Replacement Bulb Data:
Product #     Type Base Watts Watts Consumed Volts Hours Lumens Temp (°K) CRI
Shipping Information:
Package Type Product # Quantity UPC Length Width Height Cube Weight Frt. Class UPS Ship
Individual 7700503EN7-848 1  785652127755  13.6 12.3 8.1 0.784 2.3 0 Yes
Master Pack 7700503EN7-848 0  10785652127752
NJ Pallet   84    48 40 77 85.556 193.2 No
NV Pallet   84    48 40 77 85.556 193.2 No
