8871EN3-98: Large One Light Outdoor Wall Lantern

	Collection: Sebring
	Outdoor Wall Lantern in Black Finish with Clear Seeded Glass.
	An outdoor fixture with eye-catching style , in a black finish over aluminum. Clear seeded glass adds just the right sparkle.
	Shade interior painted white
	Supplied with 6.5-inches of wire
	For an eco-friendly lighting design, convert to LED bulbs to offer savings and reduce energy
	Designed for damp and wet environments allowing for direct water contact
	1-year manufacturer warranty
	Meets Title 24 energy efficiency standards
	UPC #:785652099878
	Finish: Brushed Stainless (98)

Dimensions:


Width:	11 1/4''
Height:	15 3/4''

Weight:

3.6 lbs.

Extends:

13 1/2''

Wire:

6 1/2'' (color/Black/White)

Mounting Proc.:

Cap Nuts

Connection:

Mounted To Box

Bulb Appearance:

Clear

Watts:

Lumens:

800

Bulb Temp:

3000 °K

Bulbs:

1 - LED Medium A19 9w Max. 120v - included

Features:

This fixture features mouth-blown glass and slight variations are an inherent part of the handcrafting process.
LED Bulbs are an efficient, versatile and durable light source that deliver exceptional performance.
Meets Title 24 energy efficiency standards
Title 24 compliant when used with included Joint Appendix (JA8) approved lamp.

Material List:

1 Body - Aluminum - Brushed Stainless

1 Bracket - Aluminum - Brushed Stainless

1 Canopy - Aluminum - Brushed Stainless

Safety Listing:

Safety Listed for Wet Locations

Instruction Sheets:

English (HC-571)
French (F-009)
Trilingual (English, Spanish, and French) (8871)

Shade / Glass / Diffuser Details:

Part

Material

Finish

Quantity

Item Number

Length

Width

Height

Diameter

Fitter
Diameter

Shade Top
Length

Shade Top
Width

Shade Top
Diameter

Diffuser

Glass

Clear Seeded

6 5/8

4 17/32

Backplate / Canopy Details:

Type	Height / Length	Width	Depth	Diameter	Outlet Box Up	Outlet Box Down
Back Plate			1	5 3/16	9 1/2	6 1/4

Replacement Bulb Data:

Product #			Type	Base	Watts	Watts Consumed	Volts	Hours	Lumens	Temp (°K)	CRI
97512S	Frosted		A19	Medium	9	9	120v	15000	800 230°	3000	90

Shipping Information:

Package Type	Product #	Quantity	UPC	Length	Width	Height	Cube	Weight	Frt. Class	UPS Ship
Individual	8871EN3-98	1	785652099878	16.75	14.5	19	2.671	10.1	0	Yes
Master Pack	8871EN3-98	0	10785652099875
NJ Pallet		36		48	40	72	80	363.6		No
NV Pallet		36		48	40	72	80	363.6		No
