89941EN3-71: One Light Outdoor Wall Lantern



Collection:  Bakersville

One Light Outdoor Wall Lantern in Black with Satin Etched Glass

Featured in the decorative Bakersville collection

1 A19 Medium 100 watt light bulb

Satin Etched glass shades

Easily converts to LED with optional replacement lamps

Meets Title 24 energy efficiency standards

UPC #:785652091438

Finish:   Antique Bronze (71)
Dimensions:

Width: 7 3/4''
Height: 17''
Weight: 2.8 lbs.
Extends: 8 1/2''
Wire: 6 1/2''
Mounting Proc.: Wall / Bath
Connection: Mounted To Box
Watts: 9
Lumens: 800
Bulb Temp: 3000 °K
Bulbs:
  1 - LED Medium A19 9w Max. 120v - included
Features:
  • LED Bulbs are an efficient, versatile and durable light source that deliver exceptional performance.
  • Meets Title 24 energy efficiency standards
  • Title 24 compliant when used with included Joint Appendix (JA8) approved lamp.
Material List:
1 Body - Aluminum - Antique Bronze
Safety Listing:
  Safety Listed for Wet Locations
Instruction Sheets:
English (88940 88941 89940 89941)

Shade / Glass / Diffuser Details:
Part Material Finish Quantity Item Number Length Width Height Diameter Fitter
Diameter		 Shade Top
Length		 Shade Top
Width		 Shade Top
Diameter
Shade Glass Satin Etched 6     3 9/16 6
Backplate / Canopy Details:
Type Height / Length Width Depth Diameter Outlet Box Up Outlet Box Down
Back Plate 6 3/8  4 11/16  7/8    14  3
Replacement Bulb Data:
Product #     Type Base Watts Watts Consumed Volts Hours Lumens Temp (°K) CRI
97512S Frosted     A19 Medium 9 9 120v 15000 800    230° 3000 90
Shipping Information:
Package Type Product # Quantity UPC Length Width Height Cube Weight Frt. Class UPS Ship
Individual 89941EN3-71 1  785652091438  14.7 9.7 9.8 0.809 3.15 0 Yes
Master Pack 89941EN3-71 0  10785652091435
NJ Pallet   84    48 40 77 85.556 264.6 No
NV Pallet   84    48 40 77 85.556 264.6 No
