3102803EN3-710: Three Light Chandelier


Collection:  Windom

Three Light Chandelier in Brushed Nickel Finish with Alabaster Glass Shades

Featured in the decorative Windgate collection

3 A19 Medium 100 watt light bulbs

alabaster glass shades

Easily converts to LED with optional replacement lamps

Meets Title 24 energy efficiency standards

UPC #:785652098710

Finish:   Bronze (710)
Dimensions:

Diameter: 18''
Width: 18''
Height: 16 1/2''
Weight: 4.4 lbs.
Overall Height: 54 1/2''
Wire: 72'' (color/Brown)
Chain: 36''
Mounting Proc.: Screw Collar - Chain
Connection: Mounted To Box
Watts: 9
Lumens: 800
Bulb Temp: 3000 °K
Bulbs:
  3 - LED Medium A19 9w Max. 120v - included
Features:
  • This fixture features mouth-blown glass and slight variations are an inherent part of the handcrafting process.
  • LED Bulbs are an efficient, versatile and durable light source that deliver exceptional performance.
  • Meets Title 24 energy efficiency standards
  • Title 24 compliant when used with included Joint Appendix (JA8) approved lamp.
  • Supplied with wire pre-laced through chain
Material List:
1 Body - Steel - Bronze
1 Chain - Steel - Bronze
Safety Listing:
  Safety Listed for Damp Locations
Safety Listed for Damp Locations
Instruction Sheets:
English (3102803 3102805 3102809)
Trilingual (English, Spanish, and French) (3102803 3102805 3102809)
Trilingual (English, Spanish, and French) (990CH310280_-WDM)

Shade / Glass / Diffuser Details:
Part Material Finish Quantity Item Number Length Width Height Diameter Fitter
Diameter		 Shade Top
Length		 Shade Top
Width		 Shade Top
Diameter
Shade Glass Etched / White Inside 3       4 7/8 4 1/4 1 5/8
Backplate / Canopy Details:
Type Height / Length Width Depth Diameter Outlet Box Up Outlet Box Down
Canopy 7/8      5
Replacement Bulb Data:
Product #     Type Base Watts Watts Consumed Volts Hours Lumens Temp (°K) CRI
97512S Frosted     A19 Medium 9 9 120v 15000 800    230° 3000 90
Shipping Information:
Package Type Product # Quantity UPC Length Width Height Cube Weight Frt. Class UPS Ship
Individual 3102803EN3-710 1  785652098710  8.3 16.4 13.9 1.095 4.9 0 Yes
Master Pack 3102803EN3-710 0  10785652098717
NJ Pallet   60    48 40 76 84.444 294 No
NV Pallet   60    48 40 76 84.444 294 No
