3102809-962: Nine Light Chandelier


Collection:  Windom

Three Light Chandelier in Brushed Nickel Finish with Alabaster Glass Shades

Featured in the decorative Windgate collection

3 A19 Medium 100 watt light bulbs

alabaster glass shades

Easily converts to LED with optional replacement lamps

Meets Title 24 energy efficiency standards

UPC #:785652095573

Finish:   Brushed Nickel (962)
Dimensions:

Diameter: 28''
Width: 28''
Height: 30''
Weight: 10.6 lbs.
Overall Height: 104''
Wire: 120'' (color/Clear Silver)
Chain: 72''
Mounting Proc.: Screw Collar - Chain
Connection: Mounted To Box
Bulbs:
  9 - Medium A19 75w Max. 120v - Not included
Features:
  • This fixture features mouth-blown glass and slight variations are an inherent part of the handcrafting process.
  • Easily converts to LED with optional replacement lamps
  • Meets Title 24 energy efficiency standards
  • Title 24 compliant if used with Joint Appendix (JA8) approved light bulbs listed in the California Energy Commission Appliance database.
  • Supplied with wire pre-laced through chain
Material List:
1 Body - Steel - Brushed Nickel
1 Chain - Steel - Brushed Nickel
Safety Listing:
  Safety Listed for Damp Locations
Safety Listed for Damp Locations
Instruction Sheets:
English (3102803 3102805 3102809)
Trilingual (English, Spanish, and French) (3102803 3102805 3102809)

Shade / Glass / Diffuser Details:
Part Material Finish Quantity Item Number Length Width Height Diameter Fitter
Diameter		 Shade Top
Length		 Shade Top
Width		 Shade Top
Diameter
Shade Glass Etched / White Inside 9       4 7/8 4 1/4 1 5/8
Backplate / Canopy Details:
Type Height / Length Width Depth Diameter Outlet Box Up Outlet Box Down
Canopy 7/8      5
Shipping Information:
Package Type Product # Quantity UPC Length Width Height Cube Weight Frt. Class UPS Ship
Individual 3102809-962 1  785652095573  28.3 24.1 9.1 3.592 13.75 0 Yes
Master Pack 3102809-962 0  10785652095570
NJ Pallet   18    48 40 78 86.667 247.5 No
NV Pallet   18    48 40 78 86.667 247.5 No
