3102805-710: Five Light Chandelier


Collection:  Windom

Three Light Chandelier in Brushed Nickel Finish with Alabaster Glass Shades

Featured in the decorative Windgate collection

3 A19 Medium 100 watt light bulbs

alabaster glass shades

Easily converts to LED with optional replacement lamps

Meets Title 24 energy efficiency standards

UPC #:785652095542

Finish:   Bronze (710)
Dimensions:

Diameter: 20''
Width: 20''
Height: 19 3/4''
Weight: 6.2 lbs.
Overall Height: 57 3/4''
Wire: 72'' (color/Brown)
Chain: 36''
Mounting Proc.: Screw Collar - Chain
Connection: Mounted To Box
Bulbs:
  5 - Medium A19 75w Max. 120v - Not included
Features:
  • This fixture features mouth-blown glass and slight variations are an inherent part of the handcrafting process.
  • Easily converts to LED with optional replacement lamps
  • Meets Title 24 energy efficiency standards
  • Title 24 compliant if used with Joint Appendix (JA8) approved light bulbs listed in the California Energy Commission Appliance database.
  • Supplied with wire pre-laced through chain
Material List:
1 Body - Steel - Bronze
1 Chain - Steel - Bronze
Safety Listing:
  Safety Listed for Damp Locations
Safety Listed for Damp Locations
Instruction Sheets:
English (3102803 3102805 3102809)
Trilingual (English, Spanish, and French) (3102803 3102805 3102809)

Shade / Glass / Diffuser Details:
Part Material Finish Quantity Item Number Length Width Height Diameter Fitter
Diameter		 Shade Top
Length		 Shade Top
Width		 Shade Top
Diameter
Shade Glass Etched / White Inside 5       4 7/8 4 1/4 1 5/8
Backplate / Canopy Details:
Type Height / Length Width Depth Diameter Outlet Box Up Outlet Box Down
Canopy 7/8      5
Shipping Information:
Package Type Product # Quantity UPC Length Width Height Cube Weight Frt. Class UPS Ship
Individual 3102805-710 1  785652095542  20.4 17.9 9 1.902 6.9 0 Yes
Master Pack 3102805-710 0  10785652095549
NJ Pallet   40    48 40 78 86.667 278 No
NV Pallet   40    48 40 78 86.667 278 No
