4451803-848: Three Light Wall / Bath

	Collection: Norman
	Interior of shades are Matte White
	Traditional iron forms and casual styling available in three finishes
	3 A19 Medium 60 watt light bulbs
	Black steel shades
	Easily converts to LED with optional replacement lamps
	Fixture may be mounted in the up or down position
	UPC #:785652092268
	Finish: Satin Brass (848)

Dimensions:


Width:	24 1/4''
Height:	8 7/8''

Weight:

4 lbs.

Extends:

7 3/4''

Wire:

6 1/2'' (color/Black/White)

Mounting Proc.:

Screw(s)

Connection:

Mounted To Box

Bulbs:

3 - Medium A19 75w Max. 120v - Not included

Features:

Easily converts to LED with optional replacement lamps
Fixture may be mounted in the up or down position
Meets Title 24 energy efficiency standards
Title 24 compliant if used with Joint Appendix (JA8) approved light bulbs listed in the California Energy Commission Appliance database.

Material List:

1 Body - Steel - Satin Brass

3 Shade - Steel - Matte White

Safety Listing:

Safety Listed for Damp Locations

Instruction Sheets:

Trilingual (English, Spanish, and French) (4451702 4451802 4451703 4451803)

Shade / Glass / Diffuser Details:

Part

Material

Finish

Quantity

Item Number

Length

Width

Height

Diameter

Fitter
Diameter

Shade Top
Length

Shade Top
Width

Shade Top
Diameter

Shade

Steel

Matte White

6 1/2

Backplate / Canopy Details:

Type	Height / Length	Width	Depth	Diameter	Outlet Box Up	Outlet Box Down
Back Plate	5	7	3/4		6 3/8	2 1/2

Shipping Information:

Package Type	Product #	Quantity	UPC	Length	Width	Height	Cube	Weight	Frt. Class	UPS Ship
Individual	4451803-848	1	785652092268	27.5	10.75	12	2.053	7.05	0	Yes
Master Pack	4451803-848	0	10785652092265
NJ Pallet		36		48	40	78	86.667	253.8		No
NV Pallet		36		48	40	78	86.667	253.8		No
