8638501-12: Large One Light Outdoor Wall Lantern


Collection:  Crittenden

Featured in the decorative Crittenden collection

1 A19 Medium 75 watt light bulb

Dark sky friendly. Designed to emit no light above the 90° horizontal plane. Photometry unavailable.

Easily converts to LED with optional replacement lamps

Meets Title 24 energy efficiency standards

UPC #:785652079108

Finish:   Black (12)
Dimensions:

Width: 13''
Height: 10 3/8''
Weight: 2.2 lbs.
Extends: 15 1/8''
Wire: 6 1/2'' (color/Black/White)
Mounting Proc.: Cap Nuts
Connection: Mounted To Box
Bulbs:
  1 - Medium A19 75w Max. 120v - Not included
Features:
  • Dark Sky friendly. Designed to emit no light above the 90° horizontal plane. Photometry unavailable.
  • Easily converts to LED with optional replacement lamps
  • Meets Title 24 energy efficiency standards
  • Title 24 compliant if used with Joint Appendix (JA8) approved light bulbs listed in the California Energy Commission Appliance database.
Material List:
1 Body - Aluminum - Black
Safety Listing:
  Safety Listed for Wet Locations
Instruction Sheets:
English (8438501 8538501 8638501)
Trilingual (English, Spanish, and French) (8438501 8538501 8638501)
Trilingual (English, Spanish, and French) (990W8538501-CRI)

Backplate / Canopy Details:
Type Height / Length Width Depth Diameter Outlet Box Up Outlet Box Down
Back Plate     7/8  5  3 3/8
Shipping Information:
Package Type Product # Quantity UPC Length Width Height Cube Weight Frt. Class UPS Ship
Individual 8638501-12 1  785652079108  17.25 16 13.25 2.116 4.3 0 Yes
Master Pack 8638501-12 0  10785652079105
NJ Pallet   32    48 40 75 83.333 137.6 No
NV Pallet   32    48 40 75 83.333 137.6 No
