Job Name:
 Job Type:
Comments:
 Quantity:
** By typing in the gray boxes above you can populate this form before printing.
** To save this document click on the logo above. A pdf document of this Specification Sheet will be created that can be saved locally.
8301593S-10: LED Wall Lantern in Bronze Finish


Collection:  NON/CAT Items

Featured in the decorative NON/CAT Items collection

2 A19 Medium 9.3 watt light bulb

Advanced LED technology that warms in color when dimmed (3000K - 2200K).

Powder coat added to the finish to protect against aging.

Meets Title 24 energy efficiency standards

UPC #:785652065866

Finish:   Bronze (10)
Dimensions:

Width: 5''
Height: 13''
Weight: 3.1 lbs.
Extends: 4 7/8''
Wire: 6'' (color/Black/White)
Mounting Proc.: Screw(s)
Connection: Mounted To Box
Bulb Type: Modules
Bulb Base: Integrated
Volts: 120
Watts: 7.9
Watts Consumed: 7.9
Watts Rated: 7.9
Hours Rated: 50000
Lumens: 383
Bulb Temp: 3000 °K
CRI: 90
Bulbs:
  1 - LED Integrated Array 7.9w 120v - included
Features:
  • Advanced LED technology that warms in color when dimmed (3000K - 2200K).
  • Powder coat added to the finish to protect against aging.
  • Meets Title 24 energy efficiency standards
  • Title 24 compliant high efficacy light source that is not required to be listed in the California Energy Commission Appliance database.
Material List:
1 Body - Aluminum - Bronze
Safety Listing:
  Safety Listed for Wet Locations
Instruction Sheets:

Backplate / Canopy Details:
Type Height / Length Width Depth Diameter Outlet Box Up Outlet Box Down
Back Plate 13  5  1    6 1/2
Shipping Information:
Package Type Product # Quantity UPC Length Width Height Cube Weight Frt. Class UPS Ship
Individual 8301593S-10 1  785652065866  16.2 8.1 7.7 0.585 3.6 0 Yes
Master Pack 8301593S-10 0  10785652065863
NJ Pallet   96    48 40 77 85.556 304.32 No
NV Pallet   96    48 40 75 83.333 348 No
