887193S-98: Large LED Outdoor Wall Lantern

	Collection: Sebring
	LED Outdoor Wall Lantern in Weathered Copper Finish with Clear Seeded Glass.
	An outdoor fixture with eye-catching style , in a weathered copper finish over aluminum. Clear seeded glass adds just the right sparkle.
	Featured in the decorative Sebring collection
	1 A19 Medium 100 watt light bulb
	Clear seeded glass diffuser
	Advanced LED technology that warms in color when dimmed (3000K - 2200K).
	Meets Title 24 energy efficiency standards
	UPC #:785652065200
	Finish: Brushed Stainless (98)

Dimensions:


Width:	11 1/4''
Height:	15 3/4''

Weight:

3.6 lbs.

Extends:

13 1/2''

Wire:

6 1/2''

Mounting Proc.:

Cap Nuts

Connection:

Mounted To Box

Bulb Appearance:

Clear

Bulb Type:

Modules

Bulb Base:

Integrated

Volts:

120

Watts:

Watts Consumed:

Watts Rated:

Hours Rated:

50000

Lumens:

1000

Bulb Temp:

3000 °K

CRI:

Bulbs:

1 - LED Integrated Modules 14w Max. 120v - included

Features:

This fixture features mouth-blown glass and slight variations are an inherent part of the handcrafting process.
Advanced LED technology that warms in color when dimmed (3000K - 2200K).
Meets Title 24 energy efficiency standards
Title 24 compliant high efficacy light source that is not required to be listed in the California Energy Commission Appliance database.

Material List:

1 Body - Aluminum - Brushed Stainless

1 Bracket - Aluminum - Brushed Stainless

1 Canopy - Aluminum - Brushed Stainless

Safety Listing:

Safety Listed for Wet Locations

Instruction Sheets:

English (HC-571)
French (F-009)
Trilingual (English, Spanish, and French) (8871)
Trilingual (English, Spanish, and French) (887193s)

Shade / Glass / Diffuser Details:

Part

Material

Finish

Quantity

Item Number

Length

Width

Height

Diameter

Fitter
Diameter

Shade Top
Length

Shade Top
Width

Shade Top
Diameter

Diffuser

Glass

Clear Seeded

G500319-67

6 5/8

Backplate / Canopy Details:

Type	Height / Length	Width	Depth	Diameter	Outlet Box Up	Outlet Box Down
Back Plate			1	5 3/16	9 1/2	6 1/4

Shipping Information:

Package Type	Product #	Quantity	UPC	Length	Width	Height	Cube	Weight	Frt. Class	UPS Ship
Individual	887193S-98	1	785652065200	16	14	16	2.074	5.5	0	Yes
Master Pack	887193S-98	0	10785652065207
NJ Pallet		30		48	40	74	82.222	165		No
NV Pallet		30		48	40	76	84.444	163.5		No
