89824EN-15: Medium Uplight One Light Outdoor Wall Lantern

	Collection: Brentwood
	Black Powdercoat Cast Aluminum One Light LED Outdoor Wall Lantern with White Glass. Long Decorative Panels. Mount from Bottom.
	Rugged but decorative cast aluminum. Outdoor wall lantern made with durable black powdercoat finish over cast aluminum and white glass.
	UPC #:785652024474
	Finish: White (15)

Dimensions:


Width:	10 1/4''
Height:	19 3/4''

Weight:

4.2 lbs.

Extends:

10 3/4''

Wire:

6 1/2'' (color/Black/White)

Mounting Proc.:

Center Lock-Up

Connection:

Mounted To Box

Bulb Appearance:

Clear

Bulbs:

1 - LED Medium A19 10w Max. 120v - included

Features:

ENERGY STAR® Qualified
LED Bulbs are an efficient, versatile and durable light source that deliver exceptional performance.
Powder coat added to the finish to protect against aging.

Material List:

1 Canopy - Die Cast Aluminum - White

1 Body - Die Cast Aluminum - White

1 Cap - Die Cast Aluminum - White

Safety Listing:

Safety Listed for Wet Locations
Safety Listed for Wet Locations

Instruction Sheets:

Trilingual (English, Spanish, and French) (990W8824-BRE)
Trilingual (English, Spanish, and French) (990W8_24-BRE)

Shade / Glass / Diffuser Details:

Part

Material

Finish

Quantity

Item Number

Length

Width

Height

Diameter

Fitter
Diameter

Shade Top
Length

Shade Top
Width

Shade Top
Diameter

Panel

Glass

Smooth White

3 5/8

7 11/16

Backplate / Canopy Details:

Type	Height / Length	Width	Depth	Diameter	Outlet Box Up	Outlet Box Down
Back Plate	6 7/16	4 1/4	3/4		15	4 3/4

Replacement Bulb Data:

Product #			Type	Base	Watts	Watts Consumed	Volts	Hours	Lumens	Temp (°K)	CRI
E10A19DLED27JA8	Frosted		A19	Medium	10	10	120v	25000	800	2700	90

Shipping Information:

Package Type	Product #	Quantity	UPC	Length	Width	Height	Cube	Weight	Frt. Class	UPS Ship
Individual	89824EN-15	1	785652024474	15.25	13.5	12.25	1.459	5.4	250	Yes
NJ Pallet		54		48	40	77	85.556	270		No
NV Pallet		54		48	40	77	85.556	270		No
